PSS Shaft Seal for 1-1/8" Diameter Shaft
PSS Shaft Seal for 1" Diameter Shaft

Our Price: $418.89

Stock Status: In Stock

Availability: Usually Ships in 24 Hours
Product Code: PSS-02118134
Qty:

Description

PSS Shaft Seal®. The Type A PSS Shaft Seal is a mechanical face seal. The sealing surface is created between the flat surfaces of the rotating stainless-steel rotor and the stationary carbon flange. The stationary carbon flange is attached to the front side of the bellow with hose clamps, and the back end of the bellow fits over the shaft log and is secured with hose clamps. The stainless-steel rotor is fit on the shaft in front of the carbon flange. The stainless-steel rotor is used to compress the bellow before the rotor is secured to the shaft with set-screws. This compression (pre-load) maintains constant contact between the two flat faces of the stainless-steel rotor and carbon flange, allowing the PSS to compensate for the variable fore and aft movement due to propeller thrust. The carbon flange is over-bored to the shaft diameter allowing it to “float” around the shaft and thus compensate for most misalignment and vibration problems. The stainless-steel rotor is sealed to the shaft by two O-rings that are recessed into the bore of the collar. These O-rings rotate with the shaft and stainless-steel rotor and do not experience wear during operation.

  • Shaft Size: 1-1/8"
  • Hose size: 1-3/4"
  • Requires water for cooling
